ST2068
Low power consumption: 1μA typical (VDD =3.0V,Ta=25°C).
Operating voltage:1.5V~5.5V.
Operating temperature:-40℃~+85C.
ROHS Recognized
Standard IIC bus interface, maximum speed 400KHz (4.5V~5.5V).
Chip pin ESD>4KV
CMOS Process
Package Form:SOP8/TSSOP8.
Model :
ST2068REAL TIME CLOCK IC(External Crystal Oscillator)
IIC Bus Communication Disable Function in Built-inVBAT Mode
Internal three clock data write protection bits
Built-in IIC bus 0.5 seconds automatic reset function
2 bytes general SRAM implemented for system data backup
Auto reload 8-bit countdown timer
Built-in clock data write-protection function
Built-in power-on reset circuit
Built-in power supply regulator
