FEATURE
①Dimension 20.4 x 12.8 x 11mm, pypical
②Low Phase Noise & Low G-Sensitivity
③Small Hermetically Sealed Package
④Tight Frequency Stability
⑤Low Power Consumption
⑥Fast Warm-up Time
⑦Electrical Frequency Tuning Input
⑧RoHS-Compliant (lead-free)
TYPICAL APPLICATION
①Instrument Reference
②Microwave Communication
③Clock Reference for Microwave Signal Source
④Test & Measurement
⑤Telecom Systems
⑥Radar Systems
Type :
AG8Model :
POC2012Package size :
20.4*12.8*11mmFrequency :
10.000M~100.000MOven Controlled Crystal Oscillator(OCXO) POC2012
POC2012 Series SMD OCXO Crystal Oscillator (10.0MHz~100.000MHz) features a compact 2012 package (20.4×12.8×11mm) with excellent ±50ppb frequency stability, ultra-low phase noise (-100dBc/Hz@10Hz), and low aging (±5ppb/day). It offers ±2ppm voltage tuning and operates from -20°C to +70°C, ideal for communications, radar, and precision instruments. RoHS compliant, high reliability.
1. ELECTRICAL SPECIFICATIONS
| No. | Item | Electrical Specification | Remark | |||||
| Min. | Type | Max. | Units | |||||
| OUTPUT (PIN = “R.F. OUTPUT”) | ||||||||
| 1 | Nominal Frequency | 10.000 | 100.000 | MHz | ||||
| 2 | Initial Accuracy | -0.2 | +0.2 | ppm | @ +25 ±1°C,after turn on power 60 minutes,Vco=+5V | |||
| 3 | Waveform | Sine wave | ||||||
| 4 | Level | 8 | dBm | |||||
| 5 | Load | 50 | Ω | |||||
| 6 | Harmonics | -30 | dBc | |||||
| 7 | Spurious | -80 | dBc | |||||
| FREQUENCY STABILITY | ||||||||
| 8 | Ambient | ±50 | ±100 | ppb | referenced to 25°C | |||
| 9 | Aging | Daily | -5 | +5 | ppb | After 30 days. | ||
| yearly | -500 | +500 | ppb | |||||
| 10years | -1.7 | +1.7 | ppm | |||||
| 10 | Voltage | -20 | +20 | ppb | ±5% change | |||
| 11 | Short term | 0.05 | ppb | root Allan variance for τ=1 sec | ||||
| 12 | Load | -10 | +10 | Hot Tags :
