ST8938
Low power consumption: 0.6μA typical(Ta=25C).
Operating voltage: 1.8V~5.5V;Timekeeping voltage:1.5~5.5V.
Operating temperature:-40C~+105C.
Accuracy at room temperature is<±5ppm.
Standard IC bus interface mode, maximum speed 400kHz.
Chip pin ESD>4KV
Pass 4 kV EFT Interference Test
CMOS Process
Package Form:SOP8(150mil)
Model :
ST8938REAL TIME CLOCKIC(Built-in Crystal Oscillator) ST8938
Built-in 1/1024 second register
Built-in IIC bus 0.5 seconds auto reset function
Built-in temperature register
Built-in Communication Verification Function
Built-in 70-Byte General-Purpose SRAM Registers
Built-in clock data write-protection function
Built-in 8-Byte ID
